MMBT16CVFWB Caterpillar Puller Debuting at MedTec Japan April 9-11

Are you looking to enhance your manufacturing process in the medical device industry? MMBT16CVFWB a 16 carrier vertical medical braider with caterpillar puller, makes its debut at MedTec Japan on April 9-11. Visit booth 1500 and booth 1600.

MMBT16CVFWB is an innovative medical braider designed to meet the specific needs of med device manufacturers. Offering a range of benefits to improve efficiency and quality of medical braids.

MMBT16CVFWB Fine Wire Medical Braider Features

• Heavy-Duty Aluminum Frame
• Stainless and Alloy Steels
• Quiet Operation
• Non-Contact Auto Stop For:
  • Wire Breaks
  • Empty Bobbin
• Light Tower Indicator
  • Green = OK to Run
  • Red = Fault Condition
• Cost-Effective
• Door Interlocks
• High Output
• Diverse Range of Braids
  • Herringbone
  • Diamond
  • Half Load
• 1 -8 Triaxials Optional Triaxial Kit Available
• Product Size 0 (no core) to 12.5mm
• 600 picks/min
• 300 rpm
• 8 horn gears
• 1-200+ picks per inch
• Nitrile (NBR) Rubber Caterpillar Puller
• Custom Die Guides
• Measuring Camera & Monitor Included
• Carriers with triple nylon rollers to minimize friction

Quiet Operating Fine Wire Medical Braider

MMBT16CVFWB is equipped with 16 carriers and 8 horn gears, providing a high level of precision and control during the manufacturing process. The horn gears and plates are constructed from alloy steel and hardened for long-lasting durability, ensuring reliable performance over time. The track plate is made from stainless steel. NBR caterpillar puller is 10"L by 1" Wide. A purchase of an optional triaxial kit allows for triaxial braiding from 1 to 8 triaxials.

Role of Caterpillar Pullers in Braiding

Caterpillar pullers are used in medical device production to braid catheters, stents and surgical sutures. Caterpillar pullers are an essential component in medical braiders. Caterpillar pullers maintain tension on the medical braid. Uniform tension on the braided med device ensures a consistent result.

Consistent Tension Maintained

Caterpillar Pullers help grip and guide the braid firmly. Caterpillar pullers grip the braid firmly as the braid is pulled through the medical braider. Consistent tension is maintained which ensures that the braid is tight and uniform.

Ensure Accurate Product Dimensions

Caterpillar Pullers help maintain accurate product dimensions. Caterpillars ensure the diameter and wall thickness stay consistent. This is vital for applications needing precise specifications.

How does the MMBT16CVFWB benefit manufacturers?

One of the key advantages of the MMBT16CVFWB is its ability to run at different speeds and offer various braid angle controls. This flexibility allows manufacturers to tailor the machine to different types of fibers or wires, optimizing the production process for specific requirements.

MMBT16CVFWB can braid a variety of wires and fibers:

WIRES: Stainless Steel, Copper, Niti, Titanium, Gold, Platinum and Cobolt-Chromium.

FIBERS: Nylon, Polyester, Dyneema, Kevlar, Vectran, Spectra, PET, PEN, PP, PEEK and LCP.

Performance specifications of MMBT16CVFWB

MMBT16CVFWB operates at a speed of 600 peaks per minute, with the capability of 1-200+ picks per inch. This high-speed performance, combined with the ability to adjust the braid angle, ensures efficient and precise manufacturing of medical devices.

Monitor Braid Quality and Picks Per Inch

All MMBT medical braiders come with a measuring camera microscope (MMBT220x) and monitor. This allows you to view the quality of the braid live in real time and check the picks per inch (PPI) during production.

MMBT16CVFWB for medical device manufacturing

In addition to its impressive performance capabilities, the MMBT16CVFWB offers quiet operation on a cost-effective platform. The machine's frame is constructed from heavy-duty aluminum, providing stability and durability, while the track plate is made of stainless steel for longevity.

With a caterpillar puller size of 10" in length and 1" in width, MMBT16CVFWB is compact yet powerful, making it an ideal choice for med device manufacturers looking to enhance their production processes.

Don't miss the opportunity to experience the benefits of MMBT16CVFWB Caterpillar Puller at MedTec Japan. Visit booth 1500 and booth 1600 to see this quiet fine wire medical braider in action and learn how it can elevate your med device manufacturing capabilities. MMBT's team will be there to answer any questions you have.
