MMBT by Metro CAD at FIME June 19-21, 2024.

Please stop by Booth #J98 and hear how quiet MMBT16CHFWB our 16-carrier horizontal braider is.

MMBT sells both horizontal and vertical braiders in carrier configurations of 16 | 24 | 32 | 48 | 64 | 72 | 96 | 144 | 288.

MMBT16CHFWB is a state-of-the-art Digital Round Braider with quiet operation on a cost-effective platform.

MMBT16CHFWB Quiet Operating Medical Braider

• 80.1 dB at 100% Machine Speed (300 RPM)
• 74 dB at 50% Machine Speed (150 RPM)

A wide range of projects can be produced by changing the basic thread/wire diameter and number of threads/wires per carrier. Three basic patterns are Diamond, Herringbone and Half Load.

MMBT medical braiders are triaxial braiding capable. MMBT16CHFWB has 16 spring-loaded virgin nylon carriers with carbide eyelets and optional triaxial kit from 1 to 8 triaxials. MMBT's 16 carrier medical braider has 4 horns per gear that can rotate @ 300 RPM and have up to 600 picks/min. Up to 10 segments can be programmed in one recipe, allowing for different PPI for each segment.

Schedule a demo. See a braider in person stop by Metro CAD Monday - Friday 8 am - 4:30 pm.

Product size for the MMBT16CHFWB is 0 (no core) to 12.5 mm.

MMBT's 16-carrier horizontal fine wire medical braider can braid a variety of wires and fibers, some examples are:

WIRES: Stainless Steel, Copper, Niti, Titanium, Gold, Platinum and Cobolt-Chromium.

FIBERS: Nylon, Polyester, Dyneema, Kevlar, Vectran, Spectra, PET, PEN, PP, PEEK and LCP.

Elegant design, rigid structure, & high output with easy operation.

Machine operating elements are grouped on a separate intuitive HMI panel for the ease of operation and clear visibility.

Please contact us for a quote.

For Continental USA, lease to buy options available.
