Circon Eyelets Rolled Flange Brass Nickel LOT of 100ea CE-126-BN

Circon Eyelets Rolled Flange Brass Nickel LOT of 100ea CE-126-BN

$25.00
$0.00 $25.00
Sale Sold out
Shipping calculated at checkout.

17 in stock

Circon Eyelets, Rolled Flange Brass, Nickel Plated, #CE-126-BN

Rolled Flanged Eyelets

  • Brass (QQ-613B) or Copper (QQ-576B-OFHC)
  • All Finishes Standard 25 Millionths Shot-Burnished
  • Annalar spring tension uniform on all parts.
  • Perfect head form on every eyelet
  • Annealed to prevent spliting of roll

Minimum Order ---100 Eyelets 1 Lot

MicroEyelet Specifications         ROLLED FLANGE EYELETS

      (A)   (B)   ( C )   (D) Board Setting
  Part No. Material Barrel OD   Barrel ID   Flange Dia.   Length U.F. Thickness Tool
                    Nominal

  CE 22* b 0.03   0.02   0.06   0.062 1/32 CET-2
  CE23* b 0.03   0.02   0.06   0.093 1/16 CET-2
  CE 30* b/c 0.047   0.035   0.079   0.048 1/64 CET-3
  CE 32* b/c 0.047   0.035   0.079   0.062 1/32 CET-3
  CE 33* b/c 0.047   0.035   0.072   0.093 1/16 CET-3
  CE 34* b/c 0.047   0.035   0.079   0.125 3/32 CET-3
  CE 35* b/c 0.047   0.035   0.072   0.156 1/8 CET-3
  CE 42 b/c 0.06   0.045   0.105   0.062 1/32 CET-4
  CE 43 b/c 0.06   0.045   0.105   0.093 1/16 CET-4
  CE 44 b/c 0.06   0.045   0.105   0.125 3/32 CET-4
  CE 45 b 0.06   0.045   0.105   0.156 1/8 CET-4
  CE 46 b 0.06   0.045   0.105   0.187 5/32 CET-4
  CE 47 b 0.06   0.045   0.105   0.219 3/16 CET-4
  CE 63 b 0.09   0.071   0.15   0.093 1/16 CET-6
  CE 64 b/c 0.09   0.071   0.15   0.125 3/32 CET-6
  CE 65 b 0.09
